AC Surge Protective Devices
Specifications

Mineral Source Reporting for GDT, SPD, MOV CMRT

Product Series
Parametric Table
RoHS Files
Collateral
Videos
Request Samples
Contact Us
Series Data Sheet Photo Description Applications Installation Instructions Design Files Engineering Buy Now
1202 Series 1202 Series 1202_part Hardwired Type 1 AC Hybrid SPD - 25 kA/10 kA (Imax, In) Rated Full mode hybrid design SPD employing high energy MOV and Gas Discharge Tubes, Rated at 25 kA (8/20 µs) max./1 operation. Listed to UL 1449 4th edition. Suitable for latest NEC compliance. 1202 Installation
Downloads Buy
1251 Series 1251 Series 1252_part Heavy Duty Type 1 Hybrid AC SPD - 50 kA Rated Hybrid design combining MOV and GDT technology - ideal for any AC infrastructure requiring fast responding, low leakage overvoltage protection. Rated at 50 kA (8/20 µs) and listed to UL 1449. 1251 & 1252 Installation
Buy
1252 Series 1252 Series 1252_part Heavy Duty Type 2 Hybrid AC SPD w/Filtering - 50 kA Rated Hybrid design combining MOV and GDT technology - ideal for any AC infrastructure requiring fast responding, low leakage overvoltage protection. Includes filtering for noise mitigation. Rated at 50 kA (8/20 µs) and listed to UL 1449. 1251 & 1252 Installation
Buy
1214 Series 1214 Series 1224_part Heavy Duty Type 1 AC SPD - 100 kA Rated SPD Design utilizes high energy MOVs. Rated at 100 kA (8/20 µs), this series supports all common low voltage electrical distribution modes and voltages. Listed to UL 1449. Buy
1224 Series 1224 Series 1224_part Heavy Duty Type 1 AC SPD - 200 kA Rated SPD Design utilizes high energy MOVs. Rated at 200 kA (8/20 µs), this series supports all common low voltage electrical distribution modes and voltages. Listed to UL 1449. Buy
1210 Series 1210 Series 1210_part Din-Rail Heavy Duty Type 2 AC SPD - 100 kA Rated AC protection for front end installations, main switchboard and sensitive installations without Lightning Protection Systems (LPS) 1210 Series Installation
Downloads Buy
1250 Series 1250 Series 1250_part Din-Rail General Duty Type 2 AC SPD - 50 kA Rated AC protection for front end installations, main switchboard and sensitive installations without Lightning Protection Systems (LPS) 1250 Series Installation
Downloads Buy
1200TA 1200TA 1200TA_part Efficient add-on wire connector Wiring adapter for Model 1210 and 1250 Series AC SPDs Buy
1200-BB Bus Bar 1200-BB Bus Bar 1200-BB_part Grounding Bus Bar Efficient ground connection of multiple single-pole 1210 and 1250 SPDs Buy
