ChipGuard® ESD Suppressors - AEC-Q200 Compliant

Specifications

Bourns is pleased to announce a new MLV (Multilayer Varistor) family of ESD (Electrostatic Sensitive Device) protection products to its circuit protection portfolio. The metal oxide technology of ChipGuard® ESD Suppressors provides high impulse current capability of 20 A at 8/20 µs in the ultra-small 0402 type package, for example. Learn more with our Bourns Online Product Training Module

Conflict Mineral Source Reporting for ChipGuard® devices: CMRT

Product Series

Parametric Table

RoHS Files

Collateral

Videos

Request Samples

Series	Technology	Working Voltage	Applications	Standards	MDS	Design Files	Buy Now
CG0603MLC-05E/ CG0603MLC-12E Automotive	Thin Film Polymer	5 V, 12 V	AUTOMOTIVE: Camera Links, Sensors, Touchscreen Interfaces, GPS, Antennas, USB 3.0, High-Speed Communications Buses	IEC 61000-4-2, AEC-Q200	CG0603MLC-xxE	Downloads	Buy (CG0603MLC-05E) Buy (CG0603MLC-12E)
CGA0402MLC/CGA0603MLC Automotive	Thin Film Polymer	5 V, 12 V, 24 V	AUTOMOTIVE: Camera Links, Sensors, Touchscreen Interfaces, GPS, Antennas, USB 3.0, High-Speed Communications Buses	IEC 61000-4-2, AEC-Q200	CGA0402MLC CGA0603MLC	Downloads	Buy (CGA0402MLC) Buy (CGA0603MLC)
CGA0603MLA/CGA0805MLA/CGA1206MLA Automotive	Multilayered Varistor	16 V - 56 V	AUTOMOTIVE: Camera Links, Sensors, Touchscreen Interfaces, GPS, Antennas, USB 3.0, High-Speed Communications Buses	IEC 61000-4-2, AEC-Q200	CGA0603MLA CGA0805MLA CGA1206MLA	Downloads	Buy (CGA0603MLA) Buy (CGA0805MLA) Buy (CGA1206MLA)

Model/Datasheet	MSL	Soldering Profiles	Packaging Label	Terminal	CofC	3rd Party Test Reports	MDS	China RoHS
CG0201MLA	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG0201MLA	China RoHS2 - CG ESD
CG0201MLC	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG0201MLC-05H	China RoHS2 - CG ESD
CG0201MLU	1	SMD (Semiconductor Packages)		e3	CG1	Request Report	CG0201MLU	China RoHS2 - CG ESD
CG0603MLC-05E/ CG0603MLC-12E Automotive	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG0603MLC-xxE	China RoHS2 - CG ESD
CG1206MLC	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG1206MLC	China RoHS2 EFUP50 - CG ESD
CGA0402MLC/CGA0603MLC Automotive	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CGA0402MLC CGA0603MLC	China RoHS2 - CG ESD
CGA0603MLA/CGA0805MLA/CGA1206MLA Automotive		SMD (Semiconductor Packages)	CD-LB-2	e3	CG1	Request Report	CGA0603MLA CGA0805MLA CGA1206MLA	China RoHS2 EFUP50 - CG ESD
CGxxxxMLA Series	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG0402MLA, D, E CG0603MLA, D, E	China RoHS2 EFUP50 - CG ESD
CGxxxxMLE Series	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG0402MLA, D, E CG0603MLA, D, E	China RoHS2 EFUP50 - CG ESD
MLC	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG0402MLC CG0603MLC	China RoHS2 - CG ESD
MLD	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG0402MLA, D, E CG0603MLA, D, E	China RoHS2 EFUP50 - CG ESD
MLU	1	SMD (Semiconductor Packages)	CD-LB-2	e3	CG2	Request Report	CG0402MLU CG0603MLU	China RoHS2 - CG ESD
