Power Inductors - SMD High Current, Shielded
Specifications

Bourns® High Current Shielded SMD Power Inductors feature high saturation current.

Bourns® High Current Shielded SMD Power Inductors are designed with carbonyl powder, iron powder, and metal alloy powder cores.

Bourns is a leading manufacturer and supplier of power inductors, particularly SMD high current shielded power inductors. Bourns’ innovative power inductor design utilizes a flat wire within a molded magnetically shielded housing that enables lower DC resistance and slightly higher current ratings compared to traditionally used round wire. The new inductors Bourns® Models SRP4020 and SRP7030F  are ideally suited for use in DC-DC converters for mobile electronic devices and computers, as well as data storage and voltage regulator modules. Other applications that can benefit from Bourns’ advanced power inductor design include servers, portable gaming devices, navigation systems, automotive electronics, low to medium risk medical equipment and more.

SMD power inductors used in the power supply interface and at the CAN transceiver should be shielded surface mount components capable of handling high current. The high current shielded SMD power inductor's shielded housing helps achieve the low EMI levels required in automotive designs. Bourns® SRP family of SMD power inductors combines flat wire technology and a powdered iron core to achieve a compact and efficient package. The flat wire in the high current shielded SMD power inductor exhibits increased conductivity due to maximizing the use of its surface area, thus making it capable of handling high frequency switching.

Current multifunction mobile electronics designs continually demand smaller and thinner DC-DC converter solutions that must meet high current requirements. Bourns® power inductors are designed to satisfy current application needs. For example, the dimensions of Bourns® Model SRP2010 are 2.0 x 1.6 x 1.0 millimeters (mm) and Model SRP2512 measures 2.5 x 2.0 x 1.2 mm making them ideal for a broad range of ultra-thin electronic applications including smartphones, tablets and data storage devices. Bourns' latest SMD high current shielded power inductors offer the advantages of wirewound construction, and are designed with an iron powder core that features high saturation current and shielded construction for low magnetic radiation.

Obsolete Products marked with this symbol are currently available, although not recommended for new designs.

Mineral Source Reporting for Power Inductors: CFSI_CMRT4-01

Product Series
Parametric Table
RoHS Files
Collateral
Videos
Request Samples
Contact Us
Series Data Sheet Photo Shielded Size Inductance Range Current Range MDS Design Files Engineering Buy Now
PQ2614BHA PQ2614BHA PQ2614_part Yes 28 x 28 x 16 mm 2.2 - 33 µH 30 A PQ2614BHA-xxxK
Downloads Buy
PQ2614BLA PQ2614BLA PQ2614_part Yes 28 x 28 x 16 mm 1 - 33 µH 30 A PQ2614BLA-1R0K
PQ2614BLA-xxxK
Downloads Buy
PQ2617BHA PQ2617BHA PQ2617_part Yes 28 x 28 x 19 mm 3.3 - 33 µH 28 A PQ2617BHA-xxxK
Downloads Buy
SRP0310 SRP0310 srp0310_part Yes 3.4 x 3.1 x 1 mm 0.47 – 4.7 µH 1.8 – 5.6 A SRP0310
Downloads Buy
SRP0312 SRP0312 SRP0312_SRP0320_part Yes 3.4 x 3.1 x 1.2 mm 0.47 - 4.7 µH 1.9 - 6.6 A SRP0312
Downloads Buy
SRP0315 SRP0315 srp0315_part Yes 3.4 x 3.1 x 1.5 mm 0.47 – 4.7 µH 2.3 – 9 A SRP0315
Downloads Buy
SRP0320 SRP0320 SRP0312_SRP0320_part Yes 3.4 x 3.1 x 2 mm 0.47 - 4.7 µH 2.2 - 7.4 A SRP0320
Downloads Buy
SRP0410 SRP0410 srp0410_part Yes 4.4 x 4.1 x 1 mm 0.47 – 10 µH 1.4 – 5.2 A SRP0410
Downloads Buy
SRP0412 SRP0412 SRP0412_SRP0415_SRP0420_part Yes 4.4 x 4.1 x 1.2 mm 0.47 - 10 µH 1.7 - 7.6 A SRP0412
Downloads Buy
SRP0415 SRP0415 SRP0412_SRP0415_SRP0420_part Yes 4.4 x 4.1 x 1.5 mm 0.47 - 10 µH 1.9 - 9.3 A SRP0415
Downloads Buy
SRP0420 SRP0420 SRP0412_SRP0415_SRP0420_part Yes 4.4 x 4.1 x 2 mm 0.47 - 10 µH 1.8 - 10.5 A SRP0420
Downloads Buy
SRP0510 SRP0510 srp0510_part Yes 5.4 x 5.1 x 1 mm 0.47 – 10 µH 1.6 – 5 A SRP0510
Downloads Buy
SRP0512 SRP0512 SRP0512_SRP0515_SRP0520_part Yes 5.4 x 5.1 x 1.2 mm 0.47 - 10 µH 2.1 - 8.3 A SRP0512
Downloads Buy
SRP0515 SRP0515 SRP0512_SRP0515_SRP0520_part Yes 5.4 x 5.1 x 1.5 mm 0.47 - 10 µH 2.4 - 9.5 A SRP0515
Downloads Buy
SRP0520 SRP0520 SRP0512_SRP0515_SRP0520_part Yes 5.4 x 5.1 x 2 mm 0.47 - 10 µH 2.4 - 12.5 A SRP0520
Downloads Buy
SRP0610 SRP0610 srp0610_part Yes 7.1 x 6.7 x 1 mm 0.47 – 10 µH 2 – 4.7 A SRP0610
Downloads Buy
SRP0612 SRP0612 SRP0612_SRP0615_SRP0620_part Yes 7.1 x 6.7 x 1.2 mm 0.47 - 10 µH 2.7 - 7.7 A SRP0612
Downloads Buy
SRP0615 SRP0615 SRP0612_SRP0615_SRP0620_part Yes 7.1 x 6.7 x 1.5 mm 0.47 - 10 µH 3 - 12.5 A SRP0615
Downloads Buy
SRP0620 SRP0620 SRP0612_SRP0615_SRP0620_part Yes 7.1 x 6.7 x 2 mm 0.47 - 10 µH 3.6 - 15.5 A SRP0620
Downloads Buy
SRP1038A SRP1038A SRP1038A_part Yes 11 x 10 x 3.8 mm 0.20 - 47 µH 3 - 35 A SRP1038A (R20 - R56)
SRP1038A (1R0-470)
Downloads Buy
SRP1038AA SRP1038AA SRP1038AA_part Yes 11 x 10 x 3.8 mm 0.15 - 47 µH 3.5 - 44 A SRP1038AA (2R2 - 470) (leadframe)
SRP1038AA (R15 - 1R5) (non-leadframe)
Downloads Buy
SRP1038C SRP1038C SRP1038C_part Yes 11 x 10 x 3.8 mm 0.1 - 47 µH 3.2 - 53 A SRP1038C-1R0M-470M
SRP1038C-R10Y-R68M
Downloads Buy
SRP1038WA SRP1038WA srp1038wa Yes 11 x 10 x 3.8 mm 0.47 – 47 µH 3.6 – 34 A SRP1038WA
Downloads Buy
SRP1040 SRP1040 srp1040_part Yes 11.8 x 4.2 mm 0.15 - 15 µH 5 - 34 A SRP1040
Downloads Buy
SRP1040VA SRP1040VA srp1040va_part Yes 11 x 10 x 3.8 mm 1 - 68 µH 3.5 - 27 A SRP1040VA
Downloads Buy
SRP1045 SRP1045 srp1045_part Yes 11.0 x 4.5 mm 0.36 - 3.2 µH 8 - 23 A SRP1045
Downloads Buy
SRP1204 SRP1204 srp1204_part Yes 12.5 x 4.0 mm 0.5 - 1.8 µH 10 - 13 A SRP1204
Downloads Buy
SRP1205 SRP1205 srp1205_part Yes 12.5 x 5.6 mm 0.3 - 7.2 µH 8.3 - 18 A SRP1205
Downloads Buy
SRP1206 SRP1206 srp1206_part Yes 12.5 x 5.7 mm 0.47 - 3.3 µH 12 - 30 A SRP1206
Downloads Buy
SRP1235 SRP1235 srp1235_part Yes 13.9 x 3.7 mm 0.1 - 10.0 µH 7 - 43 A SRP1235
Downloads Buy
SRP1238A SRP1238A SRP1238A_part Yes 13.5 x 12.5 x 3.3 mm 0.1 - 10 µH 7 - 43 A SRP1238A (R10 - R47)
SRP1238A (R60 - 100)
Downloads Buy
SRP1245A SRP1245A SRP1245A_part Yes 13.5 x 12.5 x 4.8 mm 0.20 - 22 µH 6.5 - 52 A SRP1245A (R20 - R68)
SRP1245A (R82 - 220)
Downloads Buy
SRP1245C SRP1245C srp1245c_part Yes 13.5 x 12.6 x 4.7 mm 0.15 - 22 µH 7.5 - 55 A SRP1245C (R15~R68)
SRP1245C (1R0-220)
Downloads Buy
SRP1250 SRP1250 srp1250_part Yes 13.9 x 5.9 mm 0.22 - 10 µH 9 - 45 A SRP1250
Downloads Buy
SRP1265A SRP1265A SRP1265A_part Yes 13.5 x 12.5 x 6.2 mm 0.15 - 47 µH 6.5 - 55 A SRP1265A (R15 - R56)
SRP1265A (R68 - 470)
Downloads Buy
SRP1265C SRP1265C srp1245c_part Yes 13.5 x 12.6 x 6.2 mm 0.22 - 33 µH 8 - 55 A SRP1265C (R22-1R5)
SRP1265C (2R2-330)
Downloads Buy
SRP1265WA SRP1265WA srp1265wa Yes 13.6 x 12.6 x 6.2 mm 0.68 – 47 uH 5.2 – 36.5 A SRP1265WA
Downloads Buy
SRP1270 SRP1270 srp1250_part Yes 13.7 x 7.0 mm 0.32 - 10 µH 10 - 46 A SRP1270
Downloads Buy
SRP1510CA SRP1510CA SRP1510CA_part Yes 16.5 x 15.5 x 9.7 mm 4.7 - 33 µH 18.7 - 43 A SRP1510CA
Downloads Buy
SRP1513CA SRP1513CA SRP1513CA_part Yes 16.5 x 15.5 x 12.7 mm 4.7 - 33 µH 19 - 44 A SRP1513CA
Downloads Buy
SRP1580CA SRP1580CA SRP1580CA_part Yes 16.5 x 15.5 x 7.7 mm 1 – 5.3 µH 35 - 80 A SRP1580CA
Downloads Buy
SRP1770C SRP1770C SRP1770C_part Yes 17.8 x 16.9 x 6.7 mm 0.47 - 47 µH 8.7 - 60 A SRP1770C
Downloads Buy
SRP1770TA SRP1770TA SRP1770TA_part Yes 17.3 x 16.9 x 6.7 mm 1 - 100 µH 5.3 - 52 A SRP1770TA
Downloads Buy
SRP2010 SRP2010 SRP2010_part Yes 2.0 x 1.6 x 1.0 mm 0.24 - 2.2 µH 1.7 - 4.5 A SRP2010
Downloads Buy
SRP2010DPA SRP2010DPA srp2010dpa Yes 2.0 x 1.6 x 1.0 mm 0.47 - 4.7 µH 1.1 - 3.6 A SRP2010DPA
Downloads Buy
SRP2313AA SRP2313AA SRP2313AA_part Yes 23.5 x 22 x 12.6 mm 1 - 100 µH 11 - 70 A SRP2313AA
Downloads Buy
SRP2510A SRP2510A SRP2510_part Yes 2.5 x 2 x 1 mm 0.22 - 4.7 µH 1.36 - 5.9 A SRP2510A
Downloads Buy
SRP2512 SRP2512 SRP2512_part Yes 2.5 x 2.0 x 1.2 mm 0.47 - 2.2 µH 2.1 - 4.5 A SRP2512
Downloads Buy
SRP2512A SRP2512A SRP2510_part Yes 2.5 x 2 x 1.2 mm 0.47 - 4.7 µH 1.55 - 4.6 A SRP2512A
Downloads Buy
SRP3012C SRP3012C srp3012c_part Yes 3.5 x 3.2 x 1 mm 0.15 - 10 µH 1.1 - 10 A SRP3012C
Downloads Buy
SRP3012TA SRP3012TA SRP3012TA_SRP3020TA_part Yes 3.5 x 3.2 x 1 mm 0.15 - 10 µH 1 - 10 A SRP3012TA
Downloads Buy
SRP3020C SRP3020C srp3020c_part Yes 3.5 x 3.2 x 1.8 mm 0.1 - 10 µH 1.3 - 10 A SRP3020C
Downloads Buy
SRP3020TA SRP3020TA SRP3012TA_SRP3020TA_part Yes 3.5 x 3.2 x 1.8 mm 0.1 - 10 µH 1.4 - 10.5 A SRP3020TA
Downloads Buy
SRP3212 SRP3212 srp3212_part Yes 3.2 x 2.5 x 1 mm 0.33 – 4.7 µH 2.2 – 8.5 A TBD
Downloads Buy
SRP4012TA SRP4012TA SRP4012TA_part Yes 4.45 x 4 x 1 mm 0.1 - 10 µH 1.3 - 11.5 A SRP4012TA
Downloads Buy
SRP4018FA SRP4018FA srp4018fa_part Yes 4.1 x 4.1 x 1.8 mm 0.33 - 1.2 µH 9.5 - 15 A SRP4018FA
Downloads Buy
SRP4020FA SRP4020FA SRP4020FA_SRP4030FA_part Yes 4.1 x 4.1 x 1.9 mm 0.47 - 4.7 µH 5.1 - 13.2 A SRP4020FA
Downloads Buy
SRP4020TA SRP4020TA SRP4020TA_part Yes 4.45 x 4 x 1.8 mm 0.1 - 22 µH 1.2 - 12 A SRP4020TA
Downloads Buy
SRP4030FA SRP4030FA SRP4020FA_SRP4030FA_part Yes 4.1 x 4.1 x 2.8 mm 0.9 - 6.8 µH 4 - 11.2 A SRP4030FA
Downloads Buy
SRP5015TA SRP5015TA SRP5015TA Yes 5.7 x 5.2 x 1.3 mm 0.15 - 22 µH 1.2 - 16 A SRP5015TA
Downloads Buy
SRP5020C SRP5020C srp5020c_part Yes 5.7 x 5.2 x 1.8 mm 0.1 - 10 µH 2.5 - 20 A SRP5020C
Downloads Buy
SRP5020TA SRP5020TA SRP5020TA_part Yes 5.7 x 5.2 x 1.8 mm 0.33 - 10 µH 2.3 - 12 A SRP5020TA
Downloads Buy
SRP5030C SRP5030C srp5020c_part Yes 5.7 x 5.2 x 2.8 mm 0.1 - 10 µH 2.8 - 25 A SRP5030C
Downloads Buy
SRP5030CA SRP5030CA SRP5030CA_SRP6030CA_part Yes 5.5 x 5.3 x 2.9 mm 0.15 - 4.7 µH 5.9 - 22.2 A SRP5030CA
Downloads Buy
SRP5030T SRP5030T SRP5030T_part Yes 5.7 x 5.2 x 2.8 mm 0.33 - 15 µH 2.1 - 14 A SRP5030T
Downloads Buy
SRP5030TA SRP5030TA SRP5030TA Yes 5.7 x 5.2 x 2.8 mm 0.1 - 10 µH 2.75 - 23 A SRP5030TA
Downloads Buy
SRP5050FA SRP5050FA SRP5050FA_part Yes 5.5 x 5.3 x 4.8 mm / 6 x 5.7 x 4.8 mm 5.6 - 22 µH 3.4 - 7.2 A SRP5050FA
Downloads Buy
SRP6030CA SRP6030CA SRP5030CA_SRP6030CA_part Yes 6.6 x 6.4 x 2.9 mm 0.18 - 4.5 µH 7 - 32 A SRP6030CA
Downloads Buy
SRP6030VA SRP6030VA srp6030va_part Yes 7.1 x 6.6 x 2.8 mm 0.47 - 22 µH 3.4 - 20 A SRP6030VA
Downloads Buy
SRP6050CA SRP6050CA SRP6050CA_part Yes 6.6 x 6.4 x 4.8 mm 1 - 4.7 µH 8.5 - 20 A SRP6050CA
Downloads Buy
SRP6060FA SRP6060FA SRP6060FA_part Yes 6.6 x 6.4 x 5.8 mm 2.2 -22 µH 5 - 14 A SRP6060FA
Downloads Buy
SRP6530A SRP6530A srp6530a_part Yes 7.1 x 6.6 x 3 mm 0.1 - 10 µH 4 – 34 A SRP6530A (R10)
SRP6530A (R22-100)
Downloads Buy
SRP6540 SRP6540 SRP6540_part Yes 7.2 x 6.5 x 4 mm 0.56 - 47 µH 1.6 - 18 A SRP6540
Downloads Buy
SRP7020TA SRP7020TA srp7020ta_part Yes 7 x 6.6 x 1.8 mm 0.1 – 10 µH 2.8 - 21 A SRP7020TA
Downloads Buy
SRP7028A SRP7028A SRP7028A_part Yes 7.3 x 6.6 x 2.8 mm 0.10 - 33 µH 2 - 32.5 A SRP7028A
Downloads Buy
SRP7028AA SRP7028AA SRP7028AA_part Yes 7.1 x 6.6 x 2.8 mm 0.15 - 22 µH 2.5 - 30 A SRP7028AA
Downloads Buy
SRP7028C SRP7028C SRP7028C_part Yes 7.1 x 6.6 x 2.8 mm 0.1 - 22 µH 2.2 - 37.5 A SRP7028C
Downloads Buy
SRP7030 SRP7030 srp7030_part Yes 7.8 x 3.2 mm 0.1 - 10 µH 3 - 32.5 A SRP7030
Downloads Buy
SRP7030CA SRP7030CA SRP7030CA_part Yes 7.8 x 7.6 x 2.9 mm 1 - 8.2 µH 5.9 - 21.8 A SRP7030CA
Downloads Buy
SRP7030F SRP7030F SRP7030F_part Yes 7.6 x 3.0/3.2 mm 0.10 - 10 µH 3.5 - 32 A SRP7030F
Downloads Buy
SRP7050AA SRP7050AA SRP7050AA_part Yes 7.3 x 6.6 x 4.8 mm 0.47 - 47 µH 2.6 - 22 A SRP7050AA
Downloads Buy
SRP7050TA SRP7050TA SRP7050TA Yes 7.3 x 6.6 x 4.8 mm 0.33 - 68 µH 1.2 - 25 A SRP7050TA
Downloads Buy
SRP8040 SRP8040 srp8040_part Yes 8.2 x 4.2 mm 0.1 - 0.22 µH 25 - 35 A SRP8040
Downloads Buy
SRP8540A SRP8540A srp8540a_part Yes 8.8 x 8.4 x 3.8 mm 0.22 - 22 µH 3.9 - 31 A SRP8540A
Downloads Buy
