Standard Surface Mount (SMD), 2-Electrode

Bourns offers standard 2-electrode surface mount gas discharge tube devices with breakdown voltages ranging from 75-600 V. Standard GDTs are available in heavy duty, medium duty and light duty versions with performance based on key considerations of ITU K.12.

Conflict Mineral Source Reporting for GDT, SPD, MOV: CMRT

Quick link to the Sample Request: Request Sample
Series Data Sheet Description Photo Device Symbol Dimensions (Diameter x Length mm) Capacitance pF DC Breakdown Voltage Range V Nominal 8/20µs Impulse Discharge Current (kA) 10 Max 8x20µs Impulse Current (kA) 1 Application Max 10x350µs Impulse Current (kA) 1 Application Operating Temperature Range C° Packaging Options RoHS Compliant Design Files Buy Now
2003-xx-SM 2003-xx-SM Light Duty 2-Electrode Micro GDT 2003_part gdt_2_electrode 2.8 x 3.5 <0.5 75-470 1 2 Not Rated -40 to +90 Tape & Reel 2003-xx-SM Downloads Buy
2051-xx-SM 2051-xx-SM Light Duty 2-Electrode Micro GDT 2051_part gdt_2_electrode 3.2 x 4.5 <0.5 90-600 2 Not Rated Not Rated -40 to +125 Tape & Reel, Bulk 2051-xx-SM Downloads Buy
2053-xx-SM 2053-xx-SM Light Duty 2-Electrode Miniature GDT 2053_part gdt_2_electrode 4 x 4.2 <1 75-600 3 5 Not Rated -40 to +85 Tape & Reel, Bulk 2053-xx-SMLF Downloads Buy
2035-xx-SM 2035-xx-SM Long Life Light Duty 2-Electrode Miniature GDT 2035_xx_sm_part_photo gdt_2_electrode 5 x 4.4 <1 90-600 5 10 1 -55 to +85 Tape & Reel, Bulk 2035-xx-SMLF Downloads Buy
2055-xx-SM 2055-xx-SM Light Duty 2-Electrode Miniature GDT 2055_part gdt_2_electrode 6.2 x 4.2 <1 75-800 5 8 Not Rated -30 to +85 Tape & Reel, Bulk 2055-xx-SMLF Downloads Buy
2027-xx-SM 2027-xx-SM Long Life Heavy Duty 2-Electrode GDT 2035_xx_sm_part_photo gdt_2_electrode 7.92 x 6.42 <1 75-600 10 25 2.5 -55 to +125 Tape & Reel, Bulk 2027-xx-SMLF Downloads Buy
2029-xx-SMLF 2029-xx-SMLF Long Life Heavy Duty 2-Electrode GDT 2035_xx_sm_part_photo gdt_2_electrode 8 x 6 <1 90-420 20 25 5 -55 to +105 Tape & Reel, Bulk 2029-xx-SMLF Downloads Buy
