Protection Plug-In Modules - 4-Type

Specifications

All Bourns® Telephone Protectors are designed to provide highly safe and reliable protection against lightning surges, power-cross conditions and ground-potential rises.

The 4-type overvoltage and overcurrent (sneak-current) 5-pins utilize Gas Discharge Tube (GDT), Multi-Stage Protector (MSP®) and TBU® High-Speed Protector (HSP) technologies to provide primary protection for electronic equipment of twisted-pair circuits.

Bourns offers our MSP® technology which contains both solid state and GDT protection components with our "switch-grade fail-short". This technology provides the fast turn-on advantages of solid state with the robustness of the GDT and the reliability and safety of our rugged failsafe. MSP® devices have 10 times the surge life of standard GDT protectors.

The TBU® HSP is utilized for advanced overcurrent protection.

Please refer to to the Bourns® Outside Plant Products Overview Guide (PDF, 2.4MB) for further information.

Products marked with this symbol are currently available, although not recommended for new designs.

Product Series

Parametric Table

RoHS Files

Collateral

Videos

Request Samples

Series	Description	Design Files	Buy Now
2430	Sneak Current MSP®	Downloads	Buy
2440	Sneak Current GDT	Downloads	Buy
2470	Sneak Current MSP®/TBU® HSP	Downloads	Buy
85028	5-Pin Receptacle	Downloads	Buy
C-303 SS	5-Pin, 3- & 4-Type SS		Buy

Outside Plant Product Overview Guide

Model/Datasheet	Photo	MSL	Soldering Profiles	Packaging Label	Terminal	CofC	3rd Party Test Reports	MDS	China RoHS

File	Type	Size	Uploaded on	Download
Protecting High Speed Communication Ports	PDF	843.57 KB	28 May, 2015	Download
