Schutz – Station

Spezifikationen

Die Telefonschutzvorrichtungen von Bourns® bieten alle einen überaus sicheren und zuverlässigen Schutz gegen Überspannungen, Potentialunterschiede und die Anhebung des Erdpotentials durch Blitzschlag.

Die Produktlinie umfasst 5-polige, Stations- und Gefäßschutzvorrichtungen, die für den Primärschutz der Elektronik von Twisted-Pair-Systemen in Netzwerkschnittstellengeräten, Endstellen, Sockeln, Verteilern oder Kundenräumlichkeiten auf GDTs (Gasentladungsröhren), Festkörper-Thyristoren, Mehrstufenschutzvorrichtungen MSP® und Hochgeschwindigkeitsschutz TBU® HSP setzen.

Bourns wendet seine MSP®-Technologie in den Stationsschutzvorrichtungen 2377-45 und 2378-35 Digi-Guard™ sowie 2360 IPA an. Bei den MSP®-Modellen handelt es sich Hybrid-Schutzvorrichtungen, die sowohl Festkörper- als auch GDT-Schutzkomponenten sowie unseren „Switch-Grade-Failshort“ enthalten. Diese Technologie kombiniert die schnelle Ansprechzeit von Festkörpersystemen mit der Robustheit der Gasentladungsröhren und der Zuverlässigkeit und Sicherheit unserer widerstandsfähigen Failsaife-Ausfallsicherung. MSP®-Modelle haben eine zehnmal längere Lebensdauer als GDT-Vorrichtungen.

Der Hochgeschwindigkeitsschutz TBU® HSP wird für einen erweiterten Überstromschutz verwendet.

Weiteres entnehmen Sie bitte dem Bourns®-Produktüberblick Linientechnik (PDF, 2,4 MB).

Obsolete Mit diesem Symbol gekennzeichnete Produkte sind verfügbar, werden jedoch nicht für Neuentwicklungen empfohlen.

Product Series

Parametric Table

RoHS Files

Collateral

Videos

Request Samples

Serie	Datenblatt	Beschreibung	Design Dateien
2372-02		Ground / Mounting Stud
2378-35-G		Common Chamber GDT, BUG-less
2022		1/2 & 7/16 Threads	Downloads
2377-35-G	2377-35-G	Common Chamber GDT, BUG-less
2377-45		MSP® Maximum Protection	Downloads
2377-45-TBU	2377-45-TBU	Sneak Current MSP®/TBU® HSP
2378-35		MSP® Heavy Duty Protection

Produktüberblick Linientechnik

Model/Datasheet	Bild	MSL	Lötprofile	Verpackungsetikett	Anschluss	Konf.	Prüfberichte Dritter	MDB	China RoHS

File	Type	Size	Uploaded on	Download
Schutz für Hochgeschwindigkeits-Kommunikationsanschlüsse	PDF	843,57 KB	28 Mai, 2015	Download
