Current Sense Transformers

Home / Products / Magnetic Products / Current Sense Transformers
prodline_transformers_power
Specifications
Product Series
Parametric Table
RoHS Files
Collateral
Videos
Request Samples
Contact Us
Data Sheet
MDS

  Specifications

Series 055652
Data Sheet 055652
Prim./Sec.
Turns Ratio		 200:1
Current Rating 0.1 - 40 A
Inductance 96 mH
Volt-time Product
on Secondary (Max.)		 715 V-Āµs
Secondary DC
Resistance (Ohms)		 1.8
MDS 055652
